Box Stall - Standard Stall Front 10' x 7' - Hi-Hog

Hi-Hog’s outstanding box stalls will look great in any barn.

The modular stall system makes it easy to plan and install a stabling solution that will meet your needs and budget. The solid welded construction will provide safe and reliable stalls for years to come.

Stall fronts come in 10′ and 12′ lengths

• Custom lengths are available

• Stall fronts are 7’-4” high (including nylon rolling wheels)

• Stall fronts include a corner feed gate for quick access to the stall from the safety of your alley

• Two sets of clip rings can be found inside the stall front for hanging feed and water (by the feed gate & mid stall front)

• The upper grills are made with 1” OD vertical bars set safely on 4” centers (maximum 3” opening)

• Stall fronts come with a 4’ wide rolling door

• Door includes a drop-down gate so bored horses can look out into the alley

• The rolling door travels silently on 4” diameter, Nylon wheels

• Steel frame is finished with a durable semi-gloss, powder coat finish (Standard color is hunter green)

• 1-1/2” wide channel excepts standard dimensional lumber or tongue and groove. Simply slide your lumber in to the channel and secure the last board.

NOTE: Stall fronts sold as frames only. Wood is not included
