8' Predator Drag - Multi Rotary Cutter

Modern Ag

$14,917.28 USD

~~$0.00 USD~~ $14,917.28 USD

Sale Call to Order

SKU:MA-001-1008D - 040-0810-2

Starting at $339.02/mo with approved credit.

Financing

Not eligible for free shipping

Freight Charge
This item may require freight charges due to the weight or size. Our friendly staff will contact you to set up your delivery. If you have any questions please Contact Us or call 512-264-2024.

The Modern Ag 8' Predator is a CAT. 2 hitch with a 150 HP transfer gearbox with two 95 HP out board gearboxes. Modern’s durability and reliability is enhanced further through our hot-dipped galvanized deck & frame. Our smooth underdecks make for a more efficient mowing surface and less area for rust to begin.

The 8' Predator includes our Red Double Diamond Warranty: 5 Year limited warranty on gearbox and a 10 Year limited warranty on deck rust through.

Rubber guards are standard, front & rear chain guards are optional.

Features

1/2” gearbox plate
Available in pull type & quick attach lift
Cylinder and hoses are standard on pull type
Heavy duty stump jumpers & slip clutch protected
Laminated tailwheels
Solid 3/16" (7 Gauge) Deck
Quick Attach
3/4” A Frames - QA
Cat 2. Hitch Lift Type

Specifications

Cutting Width . . . . . . . . . . . 96”
Transport Width . . . . . . . . . 102”
Overall Width . . . . . . . . . . . 102”
Overall Length . . . . . . . . . . 97”
Overall Height . . . . . . . . . . 2” - 15”
Blade Overlap . . . . . . . . . . 3”
Jackstand . . . . . . . . . . . . . . Standard
Hitch . . . . . . . . . . . . . . . . . . QA Cat. II or Clevis
Blade Carrier . . . . . . . . . . . Pan Stump Jumpers
Horsepower Required (min):
Lift . . . . . . . . . . . . . . . . . . . . 50 hp
Pull . . . . . . . . . . . . . . . . . . . 45hp
Main Gearbox or Divider Box* . . . . . . . . . 150 hp
Outboard Gearbox or Center & Wings* . . . . . . 95 hp
Output Shaft Diameter . . . 2-3/8”
Cut Capacity . . . . . . . . . . . . 3”
Blade Tip Speed:
540 . . . . . . . . . . . . . . . . . . . 15,847 FPM
1000 . . . . . . . . . . . . . . . . . . 15,847 FPM
Driveline Size:
Pull Type . . . . . . . . . . . . . . . Pull-Cat. 5 CV w/ Slip Clutch
QA Lift Type . . . . . . . . . . . . QA -Cat. 4 w/Clutch
Deck Thickness . . . . . . . . . 3/16”
Side Skirt . . . . . . . . . . . . . . 1/4” x 8”
Front Safety Defl ectors . . . Chain Option
Rear Safety Defl ectors:
Rubber Guard Standard with Chain Option
Weight (Approx): . . . . . . . . QA 1975 lbs.
Pull 2370 lbs.
Standard Tires . . . . . . . . . . Laminated 600 x 9
Dual Tailwheels (Pull Type) Option
Hydraulic Level
Lift (Pull Type) . . . . . . . . . . Standard
